    8 Paneled Red Metal Fire Rated Entry Door / Galvanized Steel Material/ 65 mm Thick

    Ask Lasest Price
    Brand Name : ZHONGWO
    Model Number : ZW-GMFD15
    Certification : UL, CCC
    Price : Negotiable
    Payment Terms : western union, moneygram,cash, l/c, t/t
    Supply Ability : 600 Sets per Day
    Delivery Time : 45 Days After Payment Received
    • Product Details
    • Company Profile

    8 Paneled Red Metal Fire Rated Entry Door / Galvanized Steel Material/ 65 mm Thick

    8 Paneled Red Metal Fire Rated Entry Door / Galvanized Steel Material/ 65 mm Thick

    Fireproof Entry Door


    Product Description


    The door frame is also equipped with inlayed Fire expansion strips and installed with Fire seals.By closing there is no impact sound to hear.And thirdly the crossbeam and mullion are welded in 45 degree. The door fan made of high quality cold rolled galvanized steel plate is bent accurately through bending machine, inside of which it is filled with green environment friendly perlite plates which are key to its Fire funktion,and charackters of heat insulation and sound insulation. As to the surface treatment man introduces the process technology without welding spots, thus flat appearance.

    Technical Specification

    1. It’s designed based on GB12955-2008 Standards.

    2. Structure of Drawboard: It’s made of 0.8mm Cold Galvanized Steel Sheet bending, a part of door leaf panel.

    The Fire and anti-theft door of Zhongwo Company has excellent anti-theft performance and super Fire performance. Because of its solid structure and simple shape, it is widely used in high-rise residential buildings. The door frame which is made of high quality galvanized steel strip is rolled forming at one tiem thtough the special production line.

    Technical Parameters


    Door Closer1
    Door Frame1.2mm Cold Rolled Galvanized Steel Sheet
    Door Frame TypeBinding
    Sideboard Width100mm 120mm(with earing)
    Door Leaf2 65mm
    Door Mirror1
    Fire Lock1
    Fire Hinge8
    Fire Latch2
    Fire Intumescent Seals15*2+15*2+12*2 (W*T mm)
    Perlite Fire Door Core Board1 (300±30)kg/m³
    Drawboard1 17mm*2.4mm
    Fire Sequencer1
    Door Leaf Panel4 0.8mm Cold Rolled Galvanized Steel Sheet
    Pattern of Panel9 Square Block
    ClassA
    GradeB
    Fire Resistance Rating1.0 Hour
    NameFire-Proof Anti-Thief Door
    Dimension1200*2100 (mm)
    StandardsGB12955-2008

    Door Frame:


    Frame Depth: 130mm

    Thickness of Steel Sheet:1.2mm

    Structure: Galvanized Steel Sheet+ Reinforcing Steel+Fireproof Perlite Board

    Thickness of Reinforcing Steel: 3 mm

    Density of Fireproof Perlite: 400±40kg/m3

    Weight: 25kg/m2


    Door Leaf:


    Thickness:65mm

    Thickness of Steel Sheet: 0.8mm

    Structure: Galvanized Steel Sheet+Fireproof Perlite Board

    Density of Fireproof Perlite Board: 400±40kg/m3

    Thickness of Frieproof Perlite Board: 53mm

    Weight: 25kg/m2


    Packaging&Delivery

    1. Matured packaging team consisting of professional and well-trained packaging staff with quality packaging materials.

    2. Quick delivery within 35 days since transfer confirmed.
    3. Reliable and professional logistics services which are all in long-term cooperation with us.
    4. After-sale service: Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.


    Why Choose Us?


    1. All of our fire doors are in top quality and at competitive prices.

    2. Free pre-sales consult on any questions about fire doors.

    3. Brand Advantage: We insist purchasing to be a reliable fire doors supplier for high-end real estate agents.

    4. All fire doors can be customized as your request.

    5. Good after-sale service.

    6. More than 20 years experience in fire door industry
