Factories and Big Stores, Warehouses Super-gerade Double-track Inorganic Fire Roller Shutter Insulated Fire Shutter

Super-grade Double-track Fire Roller Shutter Made of Inorganic Cloth

The curtain surface is made of 3cm thick ceramic fiber cloth, and reinforcing steel belt is inserted inside of the cloth, so that the inorganic cloth fire roller shutter can achieve the same fire level like a steel Fire roller shutter.This product has many advantages such as light surface, smooth operation and low rolling noise.

Technical Performance:

Fire Resistance Performance:

A. Fire Integrity: 3h

B. Heat Insulation: 52℃(Average Temperature Rise on the Back Surface:≦140℃ ); 76℃(Highest Temperature Rise≦180℃); 28℃(Highest Temperature Rise on the Guide Rail≦180℃)

Breaking Strength of Fabrics of Inorganic Curtain Surface(Standard: Vertical≧600N; Crosswise≧300N):

A. Glass Fiber Decoration Cloth: Vertical 665N, Crosswise 396N

B. Fire Cloth: Vertical 848N, Crosswise 466N

C. Radiation-proof Cloth: Vertical 867N, Crosswise 456N

Tolerance of Rail Slot Depth: +0.4(Standard:±2.0mm)

Tolerance of Rail Slot Width: +0.4(Standard:±2.0mm)

Splint Spacing: 500mm(Standard: 300-500mm)

Depth of Guide Rail: 55mm(Standard:>50mm)

Fit Surface Length of Smoke-proof Device of Guide Rail: 93%(≧80% of the Guide Rail Length)

Reel Deflection: 1/2059(Standard:<1/400)

Smoke Leakage of Curtain Surface: 0.05m³/(m².min)

Height Difference between two Curtain Surfaces: 8mm(≦50mm)

Noise: 76dB(Standard:≦85dB)

Electric Opening And Closing Speed: 5.6m/min(Standard:2-7.5m/min)

Self-weight Drop Speed: 5.9m/min(Standard:≦9.5m/min)

Scope of Application:

Zhongwo steel fire roller shutter is widely used in public places such as large supermarket, shopping malls, large material market, exhibition halls, factories and big stores, warehouses etc.

Henan Zhongwo Fire Science and Technology Co., Ltd, founded in 1995, is a rapid expanding manufacturing company in fire door industry. After 24 years development Zhongwo has become a leading fire door manufacturer all over in Central China. We are always keeping good cooperation relationship with many high-end real estate builders such as Green Garden and Evergrand and many reaseach institutes such as The Architectural Design And Research Institute of Henan Province. And we have always been enjoying good reputation around our partners domestically and internationally.

Our factory concentrate on the production of all kinds of fire doors from different materials such as galvanized steel, pine wood, chinese fir wood, 201/304 stainless steel and also fire resistant floating glass. Steel fire door is our highlight product, with advanced surface treatment such as powder coating, heat transfer printing and copper wiredrawing we win great advantage for our steel fire doors of high wear tolerance,high decoration performance, anti-damp performance and anti-rusty character and so on. As far as wooden fire door is concerned, we have painting free wooden fire door series, baking paint wooden fire door series and refuge room wooden fire door series.Now we can supply more than 100,000 fire door sets a year in our more than 50000㎡ existing workshop. We also have a new factory under construction which covers a field of 30 arces in Minquan of Shangqiu City,which is 200km away from our existing factory. By then our annual production ability can reach 300,000 fire door sets.

Our production ranges also to fire roller shutters, fire windows and smoke curtains of various customized sizes, colors and materials.
